:keynav_js   JavaScript Setup Required!


:keynav_js is a fast KEYSET paginator that supports the UI. It's a Pagy-exclusive technique.

The Keynav pagination adds the numeric variables (@page, @last, @previous, @next, @in) to its instances, supporting their usage with the UI. It does so by transparently exchanging data with the client, which stores the state of the pagination.

If something goes wrong on the client side, it falls back to the :countless paginator seamlessly.

Check it out with bundle exec pagy keynav

Controller
@pagy, @records = pagy(:keynav_js, collection, **options)
  • @pagy is the pagination instance. It provides the readers and the helpers to use in your code.
  • @records is the eager-loaded Array of the page records.
keyset: {...}
Set it only to force the keyset hash of column/order pairs. (It is set automatically from the set order)
tuple_comparison: true
Enable the tuple comparison e.g. (brand, id) > (:brand, :id). It works only with the same direction order, hence, it's ignored for mixed order. Check how your DB supports it (your keyset should include only NOT NULL columns).
pre_serialize: serialize

Set it to a lambda that receives the keyset_attributes hash. Modify this hash directly to customize the serialization of specific values (e.g., to preserve Time object precision). The lambda's return value is ignored.

serialize = lambda do |attributes|
  # Convert it to a string matching the stored value/format in SQLite DB
  attributes[:created_at] = attributes[:created_at].strftime('%F %T.%6N')
end
limit: 10
Specifies the number of items per page (default: 20).
client_limit: 200

Allow the client to request a :limit up to :client_limit. A higher requested :limit is silently capped.

IMPORTANT If falsey or zero, the client cannot request any :limit.

page: force_page
Set it only to force the current :page. (It is set automatically from the request param)
request: request || hash

Pagy tries to find the Rack::Request at self.request. Set it only when it's not directly available in your code (e.g., Hanami, standalone app, test,...). For example:

hash_request = { base_url: 'http://www.example.com',
                 path:     '/path',
                 params:   { 'param1' => 1234 }, # The string-keyed params hash from the request
                 cookie:   'xyz' }               # The 'pagy' cookie, only for keynav
jsonapi: true
Enables JSON:API-compliant URLs with nested query string (e.g., ?page[number]=2&page[size]=100).
root_key: 'my_root'
Set it to enable nested URLs with nested query string ?my_root[page]=2&my_root[limit]=100. Use it to handle multiple pagination objects in the same request.
page_key: 'my_page'
Set it to change the key string used for the :page in URLs (default 'page').
limit_key: 'my_limit'
Set it to change the key string used for the :limit in URLs (default 'limit').
last
The last page.
pages
The number of pages.
previous
The previous page
next
The next page.
page
The current page.
limit
The items per page.
in
The actual items in the page.
records
The fetched records for the current page.
options
The hash of options of the object.

Let's take a new look at the diagram of the keyset pagination explained in the Keyset documentation:

                  │ first page (10)  >│ second page (10) >│ last page (9)  >│
beginning of set >[· · · · · · · · · X]· · · · · · · · · Y]· · · · · · · · ·]< end of set
                                      â–²                   â–²
                                   cutoff-X            cutoff-Y

Let's suppose that we navigate to page #3 (i.e., the last page), and we click on the link for page #2. We have stored the cutoff-X, so we can pull the 10 records after cutoff-X again as we did the first time... but are we sure that we would get the same results?

Let's suppose that the database just changed: 1 record was inserted before cutoff-X, and 2 records were deleted after cutoff-X...

                  │ page #1 (11)       >│ page #2 (8)  >│ page #3 (9)    >│
beginning of set >[· · · · · · · · · · X]· · · · · · · Y]· · · · · · · · ·]< end of set
                                        â–²               â–²
                                   cutoff-X        cutoff-Y

At this point, pulling 10 records from the cutoff-X would also get the first 2 records of page #3, and if you then navigate to page #3, you would pull the same 2 records again.

Indeed, not only have the results changed, but the cutoffs appear to have also shifted their absolute position in the set. In reality, the cutoffs have the same value as before, so they maintained their relative position in the set. However, now there is a different number of records falling into the same pages, which is totally consistent with the changes, but possibly unexpected. That is... if you have the mindset of OFFSET pagination, where the pages are split by number of records (absolute position) and not by their position relative to the records in the set.

Pagy keynav pulls the records of the already visited pages with the same filter used for the beginning of the page, compounded with the negated filter of the ending of the page. It also keeps the LIMIT, so a page never holds more records than the limit.

For example, the filtering of the page could be logically described like:

- Page #1 `WHERE NOT AFTER CUTOFF-X LIMIT 10`                    <- only ending filter
- Page #2 `WHERE AFTER CUTOFF-X AND NOT AFTER CUTOFF-Y LIMIT 10` <- combined beginning + ending filter
- Page #3 `WHERE AFTER CUTOFF-Y LIMIT 10`                        <- regular beginning filter (no cutoff for last page)

When the number of records of a visited page has changed, Pagy rebalances that page at the moment you navigate to it.

Splitting a grown page

Let's suppose that 5 records were inserted in page #2, which now holds more records than the limit of 10:

                  │ page #1 (10)     >│ page #2 (15)               >│ page #3 (9)    >│
beginning of set >[· · · · · · · · · X]· · · · · · · · · · · · · · Y]· · · · · · · · ·]< end of set
                                      â–²                             â–²
                                   cutoff-X                      cutoff-Y

When you navigate to page #2, Pagy pulls only its first 10 records and adds the new cutoff-W after them. The remaining 5 records become the new page #3, and the pages after it keep their records and shift their number by one:

                  │ page #1 (10)     >│ page #2 (10)     >│ #3 (5) >│ page #4 (9)    >│
beginning of set >[· · · · · · · · · X]· · · · · · · · · W]· · · · Y]· · · · · · · · ·]< end of set
                                      â–²                   â–²         â–²
                                   cutoff-X            cutoff-W  cutoff-Y
Merging a short page

Let's suppose that 5 records were deleted from page #2:

                  │ page #1 (10)     >│ #2 (5) >│ #3 (5) >│ page #4 (9)    >│
beginning of set >[· · · · · · · · · X]· · · · W]· · · · Y]· · · · · · · · ·]< end of set
                                      â–²         â–²         â–²
                                   cutoff-X  cutoff-W  cutoff-Y

When you navigate to page #2, Pagy finds that its records and the records of page #3 fit together in the limit. It pulls them all as page #2 and removes the cutoff-W. The pages after it keep their records and shift their number back by one:

                  │ page #1 (10)     >│ page #2 (10)     >│ page #3 (9)    >│
beginning of set >[· · · · · · · · · X]· · · · · · · · · Y]· · · · · · · · ·]< end of set
                                      â–²                   â–²
                                   cutoff-X            cutoff-Y
Rules
  • A page that holds more records than the limit is split.
  • A page that holds fewer records than the limit is merged with the next page, when the records of both fit in the limit. Otherwise it keeps its records.
  • An empty page is always removed, and the records of the next page take its place.
  • A page followed by the last page is filled with the records that follow it.
  • Two empty pages in a row restart the pagination from the first one: it shows the next records of the set, and the visited pages after it are forgotten.

So a page is empty only when no records follow it. The restart forgets the visited pages after it because the set changed too much to trust what the client knows about them: you find them again by navigating forward.

Pagy never moves the cutoff between two visited pages that hold records, because that would change the records of all the pages after it.
